The Press and Edge welding machine can be purchased as a single cell or double cell.13952_091415 032 press & weld cropped

This machine is ideal for welding stamped muffler bodies.

This machine could operate in conjunction with a component part weighing machine, in a just prior operation.



Maximum press force per station – 20,000 lbs (at 80 psi)
Two Robot Programming Platforms
Each machine side enclosure equipped with Access door
Two Tip Change Windows (one per side), accessible at floor level, with wire advance buttons
Fluorescent Work Lights with Auxiliary Disconnect
Enclosed Top Section for smoke collection and removal cuff
Reversible Start/Stop Station, and an additional E-Stop within the cell
3D Design Using AutoDesk Inventor



AB Compact Logix PLC
AB 10″ PanelView Plus Operator Interface
Frommelt Roll-up Operator Barrier with Horizontal Light Curtain
